A step by step guide to ordering and correcting charts on ECDIS

Written by Capt Rajeev Jassal on February 29, 2016
163
Many believe ECDIS has changed the way we navigate our ships. Rightly so, after all we see our ship all the times on the chart. No more worries of plotting the ship's position manually and no chances of human error in plotting the positions on paper chart. But there are many of us, who do not still agree with this. They argue that shrinking the width and height of paper chart to a 21 inch screen can bring too many confusions. They also argue that ECDIS should not be primary means of navigation till the time all ambiguities are eliminated and procedures streamlined. Which side do you see yourself ? Step by step guide for ECDIS In this post I am trying to streamline some of the procedures related to ECDIS. I strongly believe that if we deal with the ECDIS with correct approach, it would not be that difficult as it might look, specially to the seafarers working with the ECDIS for the first time. The correct approach is comparison with the paper chart. After all that is what ECDIS is replacing. I believe if everyone deal with ECDIS with that approach, it will just be a cake walk. So What all things we can do on paper charts? If we know how to do each of this on ECDIS, we know most about ECDIS. We order the paper charts for the voyage We keep the charts corrected upto latest notices to mariners. We apply any navigational warni...

Join now to access this article and much more.

Admin has placed this article behind a paywall, making it accessible only with a paid membership, which offers numerous perks:

  • Contribute to creating a platform for reading and writing without ads.
  • Enjoy all content here, including exclusive articles for members.
  • Gain access to all exclusive articles for members.

Comments (163)

.

  • Jayraj March 16, 2016
    Info was helpful to a great extent.
    6

    Rajeev Jassal April 22, 2016
    Glad to hear that Jayraj

    Tema lukyanenko September 19, 2016
    Many thanks !!!

  • AMIT March 29, 2016
    Excellent , well balanced write up......
    1

    Rajeev Jassal April 22, 2016
    Happy to hear that AMIT..

  • thurasoe April 10, 2016
    Very good knowledge in ur website.
    1

    Rajeev Jassal April 22, 2016
    Thanks for good words thurasoe

  • ABHISHEK April 22, 2016
    awaiting many more blog from u sir thanks for eloquent info
    1

    Rajeev Jassal April 24, 2016
    Thanks for being a reader ABHISHEK...

  • Igor April 28, 2016
    Hi! I was looking for GMDSS test procedures and found your amazing article. Good job, Cap! All other info is also great. But regarding ENC permits I'm not sure about: "After importing the cell permit, The ENC of the desired voyage would be available in the ECDIS." From my experience and particularly with JRC after installing all required permits you have to install all ENC again so that ECDIS could activate new ENCs.
    1

    Rajeev Jassal April 29, 2016
    Hi Igor..Glad you liked the content.. Regarding Importing ENC on ECDIS.. I never faced the requirement to import it twice to have it viewed. Can it be because of old software version of ECDIS that you might have ? May be other readers can highlight if they are facing similar thing.

  • Imran May 17, 2016
    Very good information Sir. Thank you so much for sharing.
    1

    Rajeev Jassal May 17, 2016
    I am Happy to help Imran... Let me know if you have any question.

  • Ranapratap singh May 18, 2016
    Hello Sir, very Much informative and i put a printed copy for other officers reference too. Sir could you please elaborate Regarding Base Cd's which contains Base cells as i understand. I want to know what are those Base Cells and why do we need to run these Base Cds. Second Sir,Once i have uploaded new permits for the voayge and do i need to run the Base Cds too thereafter. Thanks And Regards.
    1

    Rajeev Jassal May 19, 2016
    Glad that it helped you Rana.. To answer your query would have been a long comment so I have included that now in the post itself (before conclusion in the post). I hope that answers your query..

  • Clive May 24, 2016
    Big help sir thanks
    1

    Rajeev Jassal May 24, 2016
    Happy that it helped you Clive. Let me know if you have any question at any time.

  • Ashwani Choudhary May 30, 2016
    Great work sir. I just want to know dat can we have only one file of ENC permits for master and backup ECDIS
    1

    Rajeev Jassal May 31, 2016
    No Ashwani we cannot because each permit has the ID of the ECDIS to which it will be applicable. This is set by the ENC provider so that no one can use the same permit key multiple times. To certain extent it also brings some security in handling the ENC data.

  • Thomas Charley July 10, 2016
    How can we find EN Charts from a given BA Chart No. for example I have BA Chart 2888 & 2889 how can I find equivalent EN Chart. Please advise.
    1

    Rajeev Jassal July 12, 2016
    The simple answer is..We cannot find. Also the boundaries of a BA paper chart and EN chart (Cell) will in most cases be not same. That is if you find ENC that cover common area that of a BA chart, the ENC would most likely will not cover the exactly same area as the BA chart. ENCs are totally different from the BA paper charts.

  • Mukesh July 29, 2016
    We are receiving permit file every week via email by UKHO. I want to know if we have to apply this permit every week to ECDIS before we apply the weekly update which we generate from chart correction software.Please advise.
    3

    Rajeev Jassal July 31, 2016
    This file will be from your ENC provider and not from UKHO. This is the permits of all the ENC that are valid. So after applying this permit all your expired permits will be removed and only valid ENCs permit will be there in your ECDIS. Applying this permit has one advantage. When you apply weekly corrections from chart (after applying the permit), you will not get errors of ENC expired. Even if you do not apply this permit, the Valid ENC permit list is automatically updated when you ask for new permit and apply them upon receiving. Don't forget to delete the old permit before applying this permit.

    Mukesh August 5, 2016
    thanks for your above reply.So there is no harm if we do not apply permit every week is that correct? We will apply only once we order new ENC cell.will it be ok?

  • Mukesh July 29, 2016
    Second thing i want to know suppose for example at sea we are updating ECDIS weekly through chart correction software and the latest weekly update we applied is 30/2016 .After applying this correction vessel arrives in port where we receive AVCS DVD for 29/2016.So in this case do we need to update our base cells or not.If yes , then after applying this DVD do we need to update again the correction for 30/2016?
    9

    Rajeev Jassal July 31, 2016
    No.. after updating with the DVD, it will not remove the latest correction so no need to apply again.

    Mukesh August 5, 2016
    Thanks for your above reply.As per the things u discussed above about the ECDIS , you mentioned that DVD(Base cells) is used to update base cells same like as we receive any new edition of paper chart.So in the case of paper chart, we apply all weekly corrections after new edition of that chart was issued.What about in case of ECDIS then?

  • vijeesh kumar C August 2, 2016
    Great work sir... very helpful for both studies and for the practical application...thank u so much
    1

    Rajeev Jassal August 7, 2016
    Glad you found it useful Vijeesh..

  • harvey August 5, 2016
    what to do if the enc shows in legend have license but not installed in im using furuno ecdis
    2

    Rajeev Jassal August 7, 2016
    Harvey.. I have not worked on Furuno ECDIS but you should not hesitate to send emails to your ENC provider, correction provider (Chartco) or even Furuno through company about any error you may not be able to resolve. We sometimes hesitate to use these resources but there is no reason to hesitate.

    digjuv September 8, 2016
    You have license or permit but you don't have ENC.. Insert your latest based DVD and check if your public key is the latest public key.

  • Eyad August 6, 2016
    Good Day Capt : Thanks for the value information. I still have some issue which confuse me and I really need your assistance. . I use JRC ECDIS and Voyger planning station .. I have sent a requesion for the expired cell permits and I received as you mentioned above on a zipped file and tkt No. .. I've installed the permit but the matter is that the log shows that the license will be expired in less than 30 days whole I am doing the requestiion I put a period for six months and which confirm that is the schedule A . and do you have idea how can I update this permits on the planning station in order to keep my chart updates ?or it will be updated automatically via the usual weekly update ?and what about the tkt key for what shall I use it? pls can I keep in touch with via Email ..Thanks a lot for you cooperation .
    1

    Rajeev Jassal August 7, 2016
    I could make out these queries raised by you Eyad. 1) You ordered for 6 month license and ENC shows validity as 30 days. 2) How to update permits on voyage planning station. The issue of validity can easily be sorted out from your ENC provider by email but looks like either the permit was not installed correctly or the permit for this ENC was not included. Check the error log for the time you had installed this permit. Also you need to delete the previous permit before installing new one. Regarding voyage planning station, you need to tell it what all ENCs you have so as to give you the corrections for the ENCs. For that you need to apply the permit on this station too.

  • Vitaly August 13, 2016
    GD, Capt. Jassal! Thank you for the most comprehensive post about updating ECDIS and ordering ENCs permits which can be found in the web! Maybe you can also give advice on procedure how to make ECDIS charts spot check, for instance ENC versus RNC?
    1

    Rajeev Jassal August 21, 2016
    Thank you Vitaly. Spot checks on ECDIS will be a very good topic to write upon and I will very soon write on that.

  • paromita August 25, 2016
    good day cptain. sir, i have been following your blogs and it has helped me in many ways. i have a request. so far i have worked on ships with short routes, i have not experienced any long ocean voyages yet. it would be really helpful if you write on a topic that discusses passage plan including ocean voyages; that includes GC track and explain how to plan a route on the ecdis. also do we have to consider weather routeing while procuring charts? thank you in advance.
    2

    Rajeev Jassal August 27, 2016
    Glad you are liking the articles Paromita.. I will write on planning a passage from scratch.

    PAROMITA August 29, 2016
    thank you so much. I would be eagerly waiting for the same

  • Babu September 9, 2016
    It's very useful for my second mate oral sir thanks a lot.....
    1

    Rajeev Jassal October 9, 2016
    Glad you found it useful Babu..

  • ELANGO September 22, 2016
    Good day Capt and thank you for well written article. I like to clarify the meaning of automatic update of ECDIS ENC. I understand that the ECDIS gets the update download directly through server without human intervention. So, the question is any human input required to import update into ECDIS like how it is done in semi-automatic update? Or, is import of update into ECDIS also done automatically? I thank you very much for your expert advise. Elango (Malaysia)
    1

    Rajeev Jassal October 9, 2016
    Though I never had my hands on full automatic system but I guess there is no human intervention required on these.

  • TSEGAY TEKLU October 8, 2016
    thank u sir. this article was always in ma mind, meaning, such article prepared by comparing the paper chart and ENC. its really an illustrative. as im a 2ndmate i have got clear view which i had some ambiguity.
    1

    Rajeev Jassal October 9, 2016
    Glad you liked it Tsegay..

  • James Thompson October 10, 2016
    A grea easy to follow tutorial. I am going for my Chief Mates soon and this has been very helpful as I haven't sailed as Chart Maintenance Officer. Many thanks!
    1

    Rajeev Jassal October 16, 2016
    Glad this could be of some help to you James..

  • Ahmed October 14, 2016
    Sir its a great online help for those looking in detailed information regarding ecdis. Sir i hve new ecdis installed onboard. i hve understood that how to order chart permits but i dont know about the Base CDs .when we require to install base cds. Please explain Sir . Hope it would also be helpful for others.
    3

    Rajeev Jassal October 16, 2016
    You will be receiving base CDs every month or so. Whenever we receive this CD we need to apply this to ECDIS. Also if you have many pending base CDs you need to apply only the latest one.

    Dario October 31, 2016
    Good day captain. We receive on board new version passage manager 6.0. After instalation louse all previous data, and our outfit is empty. How to make settings, insert valid permits in pass manager, and make in that way that we receive direct update throw the Internet? Thnks in advance..

  • kartik November 11, 2016
    Sir, Thanks for explaining in deatil. I would like to add about applying correction on ECIS through UKHO site , If we dont have chartco or any other services for AVCS. We can download the weekly correction from ukho web site through this link .Downloading updates via the FTP site our public FTP website with the following login credentials (the username and password details are case sensitive). URL: FTP://ukho.gov.uk​ Username: ukhopublic Password: Public12345​. Once you log in to the site. Go to digital Product Update > AVCS S 63 > AVCS WEEKLY EXCHANGE SET. Then download the required week correction. Once dowloaded unzip the file and save in a folder ( eg WK 45). Then On JRC ECDIS click on ENC&ARCS chart folio then click OK. Insert Pen drive Into ECDIS USB slot. Go to " TOOL" in top menu. Choose " OPTION" then click " ADVANCED TAB". Then click on three dots (...) next to S-57/S-63 ( offline). Choose drive and USB folder. Click 3 times OK button. Click AUTO DETECT. Click IMPORT/UPDATE button. So now you have all cells upto date. On completion go back to ADVANCED TAB choose drive Q as you will have problem to update ECDIS from CD- ROM at later stage. Sir the above procedure was just to Add to your efforts of Helping fellow seafarers . Thanks
    1

    Rajeev Jassal November 11, 2016
    Thanks Kartik for this wonderful insight. I want to add one point to this.. We have to look into the SMS manual to ensure that corrections collected manually through UKHO websites are allowed. Many company does not allow the ship staff to collect these corrections. Even when these are requires, these need to be collected by the marine superintendent, who will pass this to the vessel.

  • Prasad November 20, 2016
    Sir, I am presently sailing. Just took yard delivery of vessel. We have Furuno Ecdis. Navtor is the service provider for Ecdis . I ordered permits thru UK hydographic catalogue. Once. They wants directly thru Ecdis. How to order permits directly from chats. Manual its not clear. Thank u ....prasad
    1

    Rajeev Jassal December 8, 2016
    Prasad.. I have not worked with Navtor. You will not find this information in Furuno manual. You should email Navtor about this for the procedure to order permits. I know there are two ways to order permit. One is "route based" and second by cell number. I am not sure what plan your company has taken for your ship. But email Navtor will solve your problem.

  • 2nd Mate Joseph December 7, 2016
    Thank you , Captain.
    1

    Rajeev Jassal December 8, 2016
    Thank you for reading Joseph..

  • ROD January 10, 2017
    Good day sir. I have question about my JRC ECDIS onboard and this is my first time to use this kind of Ecdis. First question is, I have my ENC charts expired from Ecdis and i already deleted those expired charts but if I click Tool then Option then s-63/AVCS, I found a message saying " You have 2500 chart(s). 1120 chart(s) license has (have) expired". But I delete already those expired charts. Please advise.
    3

    Rajeev Jassal January 10, 2017
    I think you need to update the cell inventory in the ECDIS. Your ENC provider most likely send this as a permit file by email every week. Let me know if this helped.

    ROD January 11, 2017
    Thank you for the reply sir. One more thing sir, Do i need a base CD for installing a new permits on JRC ECDIS? For info. i used to order ENC chart with Navtor online.

  • Fu Tang January 19, 2017
    Amazing explanation Capt., fantastic narratives, like an intriguing presentation. I'm a 3rd mate about to take on the next roll, I've read the 'using AVCS with JRC ECDIS' guide, generated some doubts: 1. ECDIS itself contains cells initially? If a brand new ECDIS, after loading the latest base CDs, all locked cells are loaded into ECDIS? or should I say, after loading the latest base CDs, all locked cells are 'floating' inside ECDIS which means they doesn't occupy capacity of the disk, only after loading the permits for desired route, corresponding cells 'fall into places' and occupy the disk capacity. 2. what's the difference between 'deleting ENC data' and 'ENC permits', ENC and permit can only come and go together or they can survive without each other? 3. what exactly is public key-IHO.CRT? it should be installed every time before chart correction or AIO correction or else? 4. what is S-57 and S-63 in plain words? and what's the difference between 'S-57 source/system chart' and 'S-63 source/system chart' ? 5. can you elaborate AIO update procedures as well?
    1

    Rajeev Jassal January 25, 2017
    1. You are right. We can say that all the charts (base cells) are already there in the ECDIS. It just require permit file to unlock it. 2) Deleting ENC permit just deletes the permit and not the base cells. It takes base cell + permit file to show the ENC on ECDIS 3) Public key-IHO CRT is for security. In simple language it detects if you are using the approved ENCs only and not some copied version which may not be good for navigation. It only need to be installed whenever a new version is released 4) S-57 and S-63 are the standard formats in which ENCs are built. Some ENCs may be built with S-57 standard and some with S-63 standard but both are IHO standards. All ECDIS equipments are made to read these ENCs made on these common standards 5) AIO update procedure is there in this blog but I will try to elaborate that in some future blog.

  • Mukesh January 25, 2017
    hello sir.we have voyager software for chart maintenance.latest weekly permit received onboard is 03/2017.Latest DVD received was 51/2016.I extracted weekly update from voyager from 52/2016 to 03/2017.Weekly update is not getting updated in ECDIS. then i deleted all permits and cells from ECDIS and put latest permit and then i inserted DVD for 51/2016 , there were 51 cells that need updation.Then after that I applied weekly update from 52/2016 to 03/2017.But ECDIS is still showing that 51 cells need updation.When I put this weekly update from voyager in ECDIS it shows me that "insert base media 3 or browse for this date exchange set".can you please help me out.thanks.
    1

    Rajeev Jassal January 25, 2017
    What is the make of ECDIS ? When you apply the weekly correction, do it show some error ? Check the progress log. If any error, send the message to voyager mentioning that error.

  • Aleks January 25, 2017
    Good Day Capt.Rajeev Recently incountered with problem regarding ECDIS.after normaly updating enc and quiting chart handler the ecdis screen become frozen along with audio alarm.after restarting the system with power button appear message "An unhandle error ocured and system will shutdown" "system hulted fatal error".
    0

  • Aleks January 25, 2017
    ECDIS maker is Sperry Vision Master FT.Any solution from you will be very welcome.thanks in advance. Best regards.
    1

    Rajeev Jassal February 5, 2017
    Hi Aleks, I have not worked on Sperry but in any case looks to be some equipment fault. You should get in touch with the maker of ECDIS.

  • Fasika meka January 29, 2017
    how came, you would see on chartco update preview, one base cell waiting to apply, while you have already collected the newly edited cell through internet.
    1

    Rajeev Jassal February 5, 2017
    I am not sure how it works when we have ECDIS connected with internet but in any case for chartco to show same information that is in ECDIS, both need to be synchronised.

  • Ron February 5, 2017
    Hi all! Is it possible to remove due enc cells (colored orange) in chartco? Thanks
    1

    Rajeev Jassal February 5, 2017
    Chartco need to have same inventory as in ECDIS. If there are some expired ENC showing in chartco, these will be removed when you apply the latest permit file to the ECDIS and chartco. The permit file is usually received weekly from the ENC provider via email. As due ENC cells are still valid, these will not (& should not be removed). If for some reason this is required to be removed, we can get in touch ENC provider and ask them to update the inventory by removing these cells. They will remove these cells and send the updated permit file. This permit file when applied to chartco and ECDIS will not have the due ENC. Let me know if you find any other information on this.

  • Tabugnam March 22, 2017
    Good day Sir. Do you know what is the name of the number in cell. ex GB302887. I know the first 2 letters is country code.
    1

    Rajeev Jassal March 28, 2017
    The 302887 is the cell number by which the cell is identified along with the country code GB.

  • Al March 26, 2017
    Sir, id like to ask if u what is the solution..if after updating the jrc ecdis...you encountered an error that says...nonsequential update.. .im thinking that there was a skipped update... What wud b the solution for this situation Sir
    0

  • Al March 26, 2017
    ... Im thinking Sir that we have skipped an update in the chartco and in the jrc ecdis..what do u think is the best solution for this situation. . .also the ecdis has an error during the updating..saying non sequential update and that there were charts not updated
    4

    Rajeev Jassal March 28, 2017
    In chartco computer, go to My computer -> C drive -> Chartco -> archive -> Passage Manager -> ENC -> Processed. These are the previous updates and one or more of these are not applied. Copy and shift the ones you think may not have been applied to the folder where you get the updated after collecting from Chartco. Collect these in USB and apply to ECDIS. Let me know if this worked.

    Al March 29, 2017
    Thank you Sir though i didnt get the part copy and shifting. . ..

  • Al April 1, 2017
    Good day Sir, thank you very much for elaborating things. Follow.up question Sir.. As per ur above example, where wud i get the previous wk 13 updates if it has been already 'confirmed and applied' on chartco and with regards to the files in 'processed' the files there are '.upd' files...is that what i need to copy and apply into the ecdis, Sir? Thank you Sir.
    0

  • Dilraj April 13, 2017
    Hiii sir....vy helpfull. Sir i hav one question. If we receive new aio base cell. Can i skip it till i receive new update cd. Coz file size is large. It has any effect on ecdis
    1

    Rajeev Jassal June 23, 2017
    Yes, we can skip these but If I am not wrong, the new version of Chartco does not allow now to proceed for corrections without downloading the base cells.

  • Elsayed April 15, 2017
    Can you tell me how i can find all list for t&p corr in ecdis c map software as we can find that in paper chart by list and enforce and canceled ?
    0

  • Mukesh May 9, 2017
    Hello sir , I hope you are doing good. I had one doubt , we have Chartco software & Kelvin hughes ECDIS onboard.Latest available DVD is 05/2017 which was applied on ECDIS & chartco as well.Now there are some permits expired end of april.Ecdis was updated till 15/2017.Latest permit received is of 18/2017.now if i remove the old permits from chartco & insert the latest permit(i.e , 18/2017) the pending corrections in chartco will be cumulative or not.will it update the ECDIS upto date ? awaiting your response.thanks in advance.
    0

  • Ricardos May 27, 2017
    Hello Capt. i have an urgent situation. Its about Sperry Marine Visionmaster. After installing the latest chart update dvd, we have lost data for 1 port. Permits are fine and no errors. However, my question, is it possible to override with an dvd older chart update. Namely, before the very last update were all charts fine.
    0

  • SANJAY JAISWAL June 14, 2017
    Sir, what is the difference between ENC and AVCS.
    0

  • SANDEEP RANA June 24, 2017
    Good day Captain, really appreciate all the efforts you have taken for assisting the seafaring community. Kindly care to clarify this doubt of mine. As mentioned earlier in one the replies you have mentioned that before applying a new permit the old permit has to be deleted. Later in another one of the replies it has been mentioned that on application of weekly permit file the old expired permits get removed automatically. Could you please clarify if this removal of expired permits needs to be done manually or happens automatically on applying the weekly permit file.
    1

    Rajeev Jassal June 29, 2018
    Actually it depends on ECDIS make. In JRC we have to delete the permit before installing a new one. On Furnuo, it gets deleted automatically. The newer version of JRC ECDIS may not require it to be deleted. So we must check if it is required to be deleted on your ECDIS or not.

  • aniket September 7, 2017
    I found your blog to be very informative and interesting. On similar lines you can also check out http://crbtech.in/Testing/guide-manual-support-testing/ which is also a very good blog on this very topic. Request you to continue writing on varied topics as we would like to read.
    0

  • Danish Pawne September 29, 2017
    very useful article sir ......... i have a request to make ....... pls if you can blog about the performance standards of Ecdis and Radar.
    0

  • Deepak November 4, 2017
    SIR, pls write a blog on Passage planning in ecdis, step wise..
    0

  • NikNik November 19, 2017
    If there are any official requirement that T&P have to be applied manually on ENC in case you dont have AIO support on ECDIS?
    1

    Rajeev Jassal June 29, 2018
    The charts are required to be updated for permanent as well as T&P corrections. If T&P are not updated with AIO, we need to find a way to update these. I cannot think of any other way than updating it manually.

  • Keshara January 18, 2018
    Thank you very much for this article sir, solved lots of my doubt about ecdis,
    1

    Rajeev Jassal June 29, 2018
    Glad you found it helpful Keshara...

  • Renee January 21, 2018
    Good day sir! I would like to ask that i have regarding permanent warning on our furuno 3000 ecdis - not up to date (sse 27). Weekly updates has been applied and yet all charts showing not up to date? What shall i do? Many thanks in advance.
    0

  • MD ISKENDER MIRKA January 30, 2018
    Dear Sir, AVC'S ENC have 5 category of charts. I want to know if I miss approch chart but that area already covered with another chart.In that case what problem I will face?I using the large covered area one and don't have the charts in between that chart. I don't face any problem. As I got zooming is not a problem in AVC'S ENC.Is it okay.If not please suggest me.
    1

    Rajeev Jassal June 29, 2018
    Zooming may look OK but it may be missing with some vital information. We need to use large scale ENCs to navigate. For overview of the area, we need to have small scale ENCs too.

  • Mahmad rafiq March 1, 2018
    How I come to know that the ecdis is updated
    0

  • Arsalan Khan March 16, 2018
    Dear Sir, I can't locate GB301387, GB3013321, GB503306,GB303433 and GB303434 in Chart World Program. Rest of the charts i can search them but could not able to locate these. Please advise.
    0

  • Jose Sonny B. Omlang March 20, 2018
    Thank you very much Captain,,, God bless you!!!
    1

    Rajeev Jassal June 29, 2018
    Thank you Jose...

  • Ankit dubey April 13, 2018
    Hello sir ... Very good blogs .. how we will come to know that our ENC on ECIDS are updated ? What are the errors in Ecdis??
    1

    Rajeev Jassal June 29, 2018
    We need to check the log. If there is no errors, then the ENCs are update. Apart from that we need to randomly cross-check the ENC update number of few ENCs.

  • Anviksha April 17, 2018
    information was very helpfull thanku.
    1

    Rajeev Jassal June 29, 2018
    Glad you found it helpful Anviksha...

  • 2/M JM GAVIOLA June 28, 2018
    Capt sir, when we receive weekly permits, do we have to delete the permit in the jrc ecdis before loading the new permit file? In furuno, deleting is not necessary. Do i have to delete the previous permit in jrc? Can i not go directly to load permit?
    1

    Rajeev Jassal June 29, 2018
    Yes. I have noticed on JRC ECDIS that if you do not delete the permit first, changes from new permits will not show up. So we need to delete the old permit from JRC ECDIS and then install new permit.

  • 2m jm gaviola July 3, 2018
    Thank you for your quick response sir. I have another question. When applying updates on jrc ecdis, is it best to un-tick the option to “view old edition”? This option can be seen on the ARCS/ENC CHART PORTFOLIO, under the “view” tab
    0

  • Akash Rajawat July 16, 2018
    Sir, information was worth a ton , can u shed some light on graphical testing of ecdis ? What it is meant for and how to do it?
    0

  • Bivash Bhattachergee July 31, 2018
    Dear sir, Thanks a lot for nice explanation on ecdis ins and out. Learn many thing from this topic.
    0

  • Sandeep Singh August 10, 2018
    Thanks sir great help for freshers to work on ecdis we got many answers for our confusions but i have one question what about raster charts updation we have to do manually Or same will update with enc updation ?
    0

  • Faisal khan August 27, 2018
    Sir your way of explanation is superb Can you tell me how to correct t & p correction on ecdis
    0

  • Daniel September 12, 2018
    Thanks for the detailed info Capt. Would like to know how to fix 'GB800001 Non-sequential update? JRC ECDIS
    0

  • Mark September 18, 2018
    Wonderful blog sir, just to confirm. I have received permits for new ENC. What is exactly the correct procedure to apply them? (JRC JAN-901B). Do I have to: 1. delete old permit 2. Import new permit 3. Apply latest base CD 4. Apply latest weekly corrections OR 1. Just to import new permit? Sir Please confirm which procedure is correct becouse now I am little bit confused. Thank you in advance!
    0

  • prem September 20, 2018
    Thanks sir, understood very clearly
    0

  • Vivek Patyal September 26, 2018
    Very well explained information sir.
    0

  • John anthony November 9, 2018
    Good day sir, my question is about T&P notices.our database is Caes from cmap We update our database weekly including the T&P ..so do i need to file the T &P received in NTM hard copy and cancelled it in annual summarry of notice to mariners NP 247(1) if applicable..even we dont have voyage chart onboard? We have full ecdis tokyo keiki
    0

  • Hermilo February 7, 2019
    Good day Captain, Thank you for this very helpful article of yours. I have a question regarding how to find the t&p corrections on ecdis for countries that t&p's are included in their enc's. Thank you in advance sir.
    0

  • George February 27, 2019
    Sir, it is very informative thank you for sharing this. .
    0

  • RAFEEK Pazheriyil Ali April 4, 2019
    Sir, for JRC, After applying weekly updates received from enc supplier all manual updates get deleted automatically for US ENCs, since am plotting all nav warnings as manual correction it requires me to plot again every week, only for US charts, any solution, thank you
    0

  • Bhaskar April 17, 2019
    Hello sir I m having on-board transas navisailor 4000 . And sea passage software.. sir after I m updating weekly updates m still getting error chart information not upto date. Enc permits expired.but when I m checking in sea passage my enc permits are showing valid.
    0

  • Benjie Nii Akutu May 12, 2019
    Hello Cap, Sir, Thanks so much for Sharing. Really appreciate .
    0

  • Anurag May 27, 2019
    Please anybody tell the limitations of ecdis... A surveyor asked me in oral..
    0

  • Surendra Mishra August 2, 2019
    Thanks sir for this wonderful article. I learned a lot from your blogs. Sir how can we plot and manage EP notice for enc shown as overlay with AIO. For T&p notices we can verify it from Admiralty t&p in force or cancelled list. But how we should approach for deleting EP notice when it is automatically removed from AIO?
    0

  • Prashant Yaduvanshi September 1, 2019
    Greatfull info for first time user's. However I am working on Transas Navi Sailor Ecdis 4000 till now everything was fine. But while uodating Week 35 into Ecdis, The Navi Planner is getting frozen and Ecdis could not be updated. I have tried many times by switching off Ecdis and restart and again follow same process. But Problem is still same. Navi Planner is not responding while updating. Any Suggestions. If any1 have faced same issue or have knowledge of solving of this issue please advise. I'll be greatfull to you. Thanks in advance. Please mail me if you have any solution. Email id- prashantkmr232@gmail.com
    0

  • Ejaj September 12, 2019
    Sir can you please explain manual correction procedure for t & p correction on ecdis?
    0

  • Solomon September 20, 2019
    Thanks sir for very helpfull inf. I have doubt could you explans. When i checking the ENC update status report in JRC ecdis it showed. 1, status: not up to date and request action: to be ordered 2,status: up to date and request action: to be ordered 3, status: not up to date and request action: to be installed So what actions do i have to do refer to 1,2,3 Thanks sir so much!
    0

  • Solomon.jr September 20, 2019
    Thanks sir for your inf I have a doubt could you explan. When i created a route in ecdis and i checking the ENC update status report i found that: 1, status : not up to date and request action : to be ordered 2, status; up to date and action request: to be ordered 3, status: not up to date and action request action: to be installed
    0

  • Tam Tam Tan Tan October 14, 2019
    Big help for beginners like me. Thank you!
    0

  • Anil Kumar Singh October 15, 2019
    Insightful as always. However pls advise which guidance or circular requires ENC management software to be on a backup computer or to have a back up otherwise?
    0

  • Ganesh Nangare December 26, 2019
    Hii, sir one querry regarding how can i review updates that are already apllied in JRC ECDIS as i can not find procedure for same. Actually we can see the updatye report in ecdis and also in the log that all corrections are applied. But how to review them in individual chats as we can see in FURUNO and transas ECDIS i.e. what changes have made after updates in that perticular charts. In furuno ecdis we can check by date dependant view so can u explain me is there any procedure to check review updates after apply. because vetting inspectors also asking the same quetions and they are not satisfied with log report or ENC update report
    0

  • nandika December 28, 2019
    thank you very much
    0

  • Sushil January 28, 2020
    Capt. Jassal, I am looking for a list of Geographical Areas corresponding to Base CD numbers. For instance I know that Base 7 is for Indian area, but where can I get an authentic list for all the CDs?
    0

  • Akhilesh January 28, 2020
    Congratulations on a detailed and informative blog. Just a small note, AIO has nothing to do with member nations including T & P's in their ENC's. Its a Admiralty service covering all paper chart T &P's. The Section which you quote under "T & P corrections Section" is independent of AIO.
    0

  • Abir February 3, 2020
    Sir I am cadet.I need to know that how will i understand that chart provider is giving me correct chart?and in any area vector chart is missing what to do ?
    0

  • Baai February 5, 2020
    Hi Sir. any idea about furuno fea 2807 system failure. i have PL 4.0 V 6.52.
    0

  • Capt Nahal February 20, 2020
    It's an great effort Capt Jassal and keep up the great work...navtor stick OPS also could be incorporated ....pre..voyage settings..etc...cheers
    0

  • Sharon Thomas May 11, 2020
    Sir, What is AIO ? Admiralty Information Overlay ?
    0

  • MOHAMED MOUSSA August 2, 2020
    Thank you for very informative essay but i want to update some information regarding to scales, ENCs are produced at various scales, depending on the intended navigational use. Six ENC “usage bands”, roughly equivalent to scale ranges, have been defined: overview (1), general (2), coastal (3), approach (4), harbour (5) and berthing (6).
    0

  • Nestor Lima October 5, 2020
    HI! What is the purpose of manual correction in ECDIS?
    0

  • Capt Zaid October 23, 2020
    It’s a good explanation. What we really need.
    0

  • AMY PETIT December 30, 2020
    Are you looking for Biology Homework Help service that do justice to all your requirements? Then hire the experts of My Assignment Help - can be beneficial in the following ways. To know the offer visit on website. Biology Homework Help
    0

  • Mihai January 7, 2021
    Good Day. I have a question... In my case I have imported newly requested permits, but from all cells that i have requested permit for... There are 5 cells that are having valid permit but are not installed... Even if i installed the latest Base Media. Any ideea why the Base media seems unable to install those 5 cells? What should i do?
    0

  • Ethan Taylor May 5, 2021
    Improve the quality of your content by checking and eliminating plagiarised content from your articles and blogs with the accurate Plagiarism checker. Harvard referencing is one of the trickiest referencing in which students face difficulty while writing. Generate this reference easily and accurately with the help of Harvard referencing generator tool and mention it in your articles in the proper format. Enhance the quality of your blogs, essays, and articles by identifying and removing the plagiarised areas with the Plagiarism checker tool. Generating Harvard referencing with the Harvard referencing generator tool is the easiest and most accurate way to avoid mistakes while writing it.
    0

  • Kartik June 17, 2021
    Dear sir. Good day. Sir I face same issues on my simrad e5024 ecids. Sir when I open avsc on line updating on my computer. Their show catalogue out of data. Could you please explain me how I was updated catalogue. And for that issues.i miss 2 week update my ecdis.
    0

  • Ethan Taylor June 29, 2021
    If you're having trouble writing great essays, you can get assistance from professionals. Get Do my essay assistance from academic experts and receive high-quality writings created to your specifications. Our website's Essay Rewriter tool will assist you in rewriting your essays without sacrificing your convenience. This Essay Rewriter software will assist you in effectively paraphrasing the content in your essay. When you're having trouble creating high-quality essays, hiring a professional Essay Writer is highly suggested. With the sophisticated Resume Builder, you can construct an impressive and dynamic resume for your job interviews and leave a lasting impression on your interviewers. The majority of students do not receive decent grades in their assignments because they do not submit them on time. Get the highest-quality, flawlessly written Assignment Writing Help and earn top grades on your assignments.
    0

  • Olivia Chiote February 11, 2022
    Thank you for sharing this information and I have some thing for you. Hi, I am Olivia chiote an education expert. this is known as a famous all assignment help company. operating system assignment help, buy homework online, economics homework help, Computer Network assignment help and more. for more:- operating system assignment help buy homework online economics homework help Computer Network assignment help
    0

  • Muhammad Abass March 13, 2023
    Very informative. Sir please can tell me about missing updates and when these are needed and from to get these.
    0

  • Muhammad Abass March 13, 2023
    Very helpful. Sir Can you please enlighten me about missing updates and when these updates are needed and for which ENCs.
    0
